Inch Size Shaft Support SKW
|
|
| Model No.︰ | SKW |
| Brand Name︰ | ZNZ |
| Country of Origin︰ | China |
| Unit Price︰ | - |
| Minimum Order︰ | - |
|
|
|
|
|
|
|
| MODEL NO. |
SHAFT DIAMETER |
MAIN DIMENSIONS |
WEIGHT(kg) |
| h |
E |
W |
L |
F |
G |
P |
B |
S |
| SKW4 |
0.25˝
6.35
|
0.6875˝
17.463
|
0.75˝
19.05
|
1.50˝
38.10
|
0.50˝
12.70
|
1.063˝
27
|
0.25˝
6.35
|
0.50˝
12.7
|
1.125˝
28.575
|
0.156˝
4.0
|
0.015 |
| SKW6 |
0.375˝
9.525
|
0.75˝
19.05
|
0.8125˝
20.637
|
1.625˝
41.28
|
0.563˝
14.3
|
1.187˝
30.16
|
0.25˝
6.35
|
0.688˝
17.46
|
1.25˝
31.75
|
0.156˝
4.0
|
0.021 |
| SKW8 |
0.50˝
12.70
|
1.0˝
25.40
|
1.0˝
25.40
|
2.00˝
50.80
|
0.63˝
16
|
1.63˝
41.4
|
0.25˝
6.35
|
0.88˝
22.35
|
1.50˝
38.10
|
0.188˝
4.8
|
0.035 |
| SKW10 |
0.625˝
15.875
|
1.0˝
25.40
|
1.25˝
31.75
|
2.5˝
63.5
|
0.688˝
17.46
|
1.75˝
44.45
|
0.31˝
7.88
|
1.0˝
25.40
|
1.875˝
47.625
|
0.218˝
5.6
|
0.052 |
| SKW12 |
0.75˝
19.05
|
1.25˝
31.75
|
1.25˝
31.75
|
2.5˝
63.5
|
0.75˝
19.05
|
2.13˝
54.1
|
0.31˝
7.88
|
1.25˝
31.75
|
2.00˝
50.80
|
0.218˝
5.6
|
0.082 |
| SKW16 |
1.0˝
25.40
|
1.50˝
38.10
|
1.5315˝
38.9
|
3.063˝
77.8
|
1.0˝
25.40
|
2.56˝
65
|
0.38˝
9.68
|
1.50˝
38.10
|
2.5˝
63.5
|
0.281˝
7.2
|
0.145 |
| SKW20 |
1.25˝
31.75
|
1.75˝
44.45
|
1.875˝
47.625
|
3.75˝
95.25
|
1.13˝
28.7
|
3˝
76.2
|
0.44˝
11.18
|
2.00˝
50.80
|
3˝
76.2
|
0.346˝
8.8
|
0.254 |
| SKW24 |
1.50˝
38.10
|
2.00˝
50.80
|
2.1875˝
55.563
|
4.375˝
111.125
|
1.25˝
31.75
|
3.5˝
88.9
|
0.50˝
12.70
|
2.25˝
57.15
|
3.5˝
88.9
|
0.346˝
8.8
|
0.362 |
| SKW32 |
2.00˝
50.80
|
2.5˝
63.5
|
2.75˝
69.85
|
5.5˝
139.7
|
1.50˝
38.10
|
4.5˝
114.3
|
0.63˝
16
|
3˝
76.2
|
4.5˝
114.3
|
0.406˝
10.5
|
0.716 |
|
|
|
|
